Project Information
The Topology Management Tool (ToMaTo) is a topology-centric network testbed. ToMaTo has been developed in the context of the German-Lab research project which has been funded by the German Ministry of Education and Research (BMBF).
Currently the testbed is run by the ToMaTo consortium and academic institutions can join it for free if they contribute resources. Thus ToMaTo continuously grows and already spans across multiple continents.
Worldwide sites
Partner institutions
University of Kaiserslautern, Germany
German-Lab Facility, Germany
University of Kansas, USA
Northwestern University, USA
University of Victoria, Canada
University of Würzburg, Germany
University of Munich, Germany
Simula Research Laboratory, Norway
NorNet Testbed, Norway
University of Darmstadt, Germany
University of Aachen, Germany
Rutgers University, USA
Clemson University, USA
University of Erlangen-Nürnberg, Germany
Main Features
Intuitive editor
Create your virtual network topology in an intuitive web-based editor. No need to write config files or code.
Up and running in seconds
Even very complex topologies can be configured and started in a few seconds.
Sites worldwide
Create topologies that go around the globe, select freely from our various sites.
Packet capturing
Have a look at what goes over the wire. Just activate packet capturing on a link and analyze the traffic in Wireshark.
Link emulation
Configure different properties like latency, packet loss or bandwidth on each link.
Graphical console
Control your virtual machines directly from a web-based console viewer. Watch your VM boot or control graphical user interfaces.
Virtual networks
Use virtual switches or external networks to connect your topology.
Different virtualization technologies
Select from full virtualization (KVM) and container virtualization (OpenVZ) for each topology component to save resources.
Pre-configured templates
Select from a wide range of pre-configures VM images spanning from Debian, Ubuntu and other Linux systems to Windows XP.
Integrated monitoring
Observe the resource usage of a whole topology or individual components.
More Information
Presentations
- ToMaTo - Overview (Presentation)
Dennis Schwerdel, University of Kaiserslautern - Malware Analysis in the ToMaTo Testbed (Screencast)
Dennis Schwerdel, Bernd Reuther and Paul Müller, University of Kaiserslautern - Creating OpenFlow Experiments via ToMaTo (Screencast)
Dennis Schwerdel, University of Würzburg
Screencasts
- Basic Usage
Create and start your first topology.
Publications
- Future Internet research and experimentation: The G-Lab approach
Dennis Schwerdel, Bernd Reuther, Thomas Zinner, Paul Müller and Phuoc Tran-Gia
TBP, Computer Networks, Available online 8 January 2014, ISSN 1389-1286 - ToMaTo a Virtual Research Environment for Large Scale Distributed Systems Research
Paul Müller, Dennis Schwerdel and Justin Cappos
TBP, PIK - Praxis der Informationsverarbeitung und Kommunikation, Available online 25 January 2014 - ToMaTo - a network experimentation tool
Dennis Schwerdel, David Hock, Daniel Günther, Bernd Reuther, Paul Müller and Phuoc Tran-Gia
7th International ICST Conference on Testbeds and Research Infrastructures for the Development of Networks and Communities (TridentCom 2011), Shanghai, China, April 2011. - Testing Mobile Apps in the ToMaTo Testbed
Dennis Schwerdel, Joachim Götze, Bernd Reuther and Paul Müller
12th Würzburg Workshop on IP: ITG Workshop "Visions of Future Generation Networks" (EuroView2012), Würzburg, Germany, July 2012. - Malware Analysis in the ToMaTo Testbed
Dennis Schwerdel, Bernd Reuther and Paul Müller
11th Würzburg Workshop on IP: ITG Workshop "Visions of Future Generation Networks" (EuroView2011), Würzburg, Germany, August 2011. - A networkless data exchange and control mechanism for virtual testbed devices
Tim Gerhard, Dennis Schwerdel and Paul Müller
9th International Conference on Testbeds and Research Infrastructures for the Development of Networks & Communities (TridentCom 2014), Guangzhou, China, May 2014
